- FULLY INSULATED, 1-13/16" (46mm) OVERALL DOOR THICKNESS
- FULL WIDTH x 24" x 1/8" (F.W. x 610mm x 3.2mm) POLYCARBONATE WINDOW FLUSH MOUNTED EACH LEAF
- FULL PERIMETER SEALS
- PERMANENT COLOR FACING
- TOP & BOTTOM CAM SHIELD/A.B.S. PLASTIC
- SAFETY CUSHION NOSING
- HOLD OPEN PIN
- MANUFACTURED TO FIT OPENING (+0",-1/8" -- 0mm, 3.2mm TOLERANCE)
- COMBINATION JAMB GUARD AND BOTTOM BEARING
Mounting Hardware
CAM LIFT HARDWARE 90° X 90°
1-1/2" (38mm) RISE IS STANDARD)
WHERE REQUIRED, SPECIFY ALTERNATE RISE CAM
(3/4" (19mm) DEEP SEAT CAM
CAM HARDWARE FACTORY ALIGNED AND PRE-PINNED
- BUMPERS -
MOLDED POLYETHYLENE
(42" -- 1067mm HIGH STANDARD)
-- HEIGHT: 24", 36", 48"
-- (610mm, 914mm, 1219mm) - IMPACT PANELS
-- PAD TYPE - CAM SWING (90° X 90° - STANDARD)
-- 90° x 135° -- 90° X 180° - JAMB GUARDS WITH CUTOUTS
-- 3" DEEP x 8 3/4" HIGH (76mm x 222mm) - FOR PRESSURE AND WIND LOADS:
ADJUSTABLE SPRING COMPENSATOR
TOP MOUNTED COMPRESSION SPRING
